1、 Product parameters

Brand: Yingpeng GYPEX

Model: EXBZ-900-50FXG

Power (W): 3200

Power supply voltage (V/Hz): Sealing machine 220/50 corner machine 380/50 or complete set 380/50

Minimum box size (L * W * H) (mm): 320 * 200 * 180

Maximum sealing size (L * W * H) (mm): 500 * 500 * 500

Sealing tape speed (m/min): 0-20

Applicable tape: BOPP, PVC, kraft paper tape

Workbench height (mm): 500-750

Sealing tape width (mm): 48/60/75

Package weight (kg): 2.5-30

Equipment weight (kg): 580

Dimensions (L * W * H) (mm): 2700 * 1900 * 1500

Explosion proof mark: Ex d e ib mb II B T4 Gb

2、 Product advantages

1. Adopting advanced explosion-proof technology, the structural design is rigorous, and the safety and reliability are high

2. High degree of automation: The entire sealing process does not require manual adjustment, with fully automated folding and sealing, unmanned operation, fast speed, greatly saving manpower

3. High efficiency: Four movements simultaneously perform automatic box sealing, with fast speed and high efficiency

3、 Manufacturing standards for this series of equipment

Explosion proof packaging machine products are only allowed to enter the market if they meet relevant national explosion-proof standards. The national standards for explosion-proof products include:;

GB 3836.1-2010 Explosive Atmosphere Part 1: General Requirements for Equipment

GB 3836.2-2010 Explosive Atmosphere Part 2: Equipment Protected by Flameproof Enclosures "d"

GB 3836.3-2010 Explosive Atmosphere Part 3: Equipment Protected by Increased Safety Type "e"

GB 3836.4-2010 Explosive Atmosphere Part 4: Equipment Protected by Intrinsic Safety Type "i"

GB 3836.9-2014 Explosive Atmosphere Part 9: Equipment Protected by Sealed Type "m"
